Prismatic Air Regulating Damper
Prismatic Air Regulating Damper is used to adjust the air quantity and pressure control between branches in ventilation installations. Thanks to its aerodynamic wing structure, it increases efficiency by creating low pressure loss in the system. Damper blade adjustment can be made with manual lever or damper motor according to the user's needs, so that air flow and pressure can be easily adjusted and the overall performance of the system is optimized.
General Features
- X It is used to adjust the air quantity and pressure control between branches in ventilation installations.
- X Thanks to its aerodynamic wing structure, it creates low pressure loss in the system.
- X If the electric current is interrupted, the blades remain in a fixed position, so the motor cables must be insulated.
- X Damper blade adjustment is made by manual lever or damper motor.
Material
- STANDARD:
- X Case Aluminum
- X Wing Aluminum
- OPTIONAL:
- X Frame Galvanized
- X Wing Galvanized
Case Types / Dimensioning
|
WIDTH W (mm) |
100 |
400 |
800 |
1000 |
1200 |
1400 |
1600 |
1800 |
2000 |
2200 |
2400 |
2500 |
|
HEIGHT H (mm) |
100 |
200 |
300 |
400 |
500 |
700 |
1000 |
1100 |
1200 |
1300 |
1400 |
1500 |
Pressure Loss and Sound Pressure Rating
|
|
Wing Angle |
|||
|
Full Open |
30o |
45o |
60o |
|
|
Air Speed (m/s) |
ΔP (Pa) |
|||
|
1 |
<5 |
<5 |
<5 |
25 |
|
2 |
<5 |
<5 |
8 |
40 |
|
4 |
<5 |
8 |
32 |
160 |
|
6 |
<5 |
14 |
55 |
275 |
|
8 |
9 |
25 |
98 |
490 |
|
10 |
13 |
36 |
142 |
710 |
|
|
Wing Angle |
|||
|
Full Open |
30o |
45o |
60o |
|
|
Air Speed (m/s) |
dB(A) |
|||
|
1 |
<40 |
<40 |
<40 |
<40 |
|
2 |
<40 |
<40 |
<40 |
45 |
|
4 |
<40 |
<40 |
<40 |
50 |
|
6 |
<40 |
<40 |
45 |
55 |
|
8 |
<40 |
<40 |
50 |
>60 |
|
10 |
<40 |
45 |
50 |
>60 |
Actuators
|
|
Engine Code |
Control |
Voltage |
Tork |
Switch |
|
On Off Motor |
LM230A |
1 wired control (Open Close) 2-wire control (3-point) |
100 - 240 V AC |
5 Nm |
- |
|
LM24A |
1 wired control (Open Close) 2-wire control (3-point) |
24 V AC/DC |
5 Nm |
- |
|
|
LM230A |
1 wired control (Open Close) 2-wire control (3-point) |
100 - 240 V AC |
5 Nm |
S2A |
|
|
LM24A |
1 wired control (Open Close) 2-wire control (3-point) |
24 V AC/DC |
5 Nm |
S2A |
|
|
NM230A |
1 wired control (Open Close) 2-wire control (3-point) |
100 - 240 V AC |
10 Nm |
- |
|
|
NM24A |
1 wired control (Open Close) 2-wire control (3-point) |
24 V AC/DC |
10 Nm |
- |
|
|
NM230A |
1 wired control (Open Close) 2-wire control (3-point) |
100 - 240 V AC |
10 Nm |
S2A |
|
|
NM24A |
1 wired control (Open Close) 2-wire control (3-point) |
24 V AC/DC |
10 Nm |
S2A |
|
|
SM230A |
1 wired control (Open Close) 2-wire control (3-point) |
100 - 240 V AC |
20 Nm |
- |
|
|
SM24A |
1 wired control (Open Close) 2-wire control (3-point) |
24 V AC/DC |
20 Nm |
- |
|
|
SM230A |
1 wired control (Open Close) 2-wire control (3-point) |
100 - 240 V AC |
20 Nm |
S2A |
|
|
SM24A |
1 wired control (Open Close) 2-wire control (3-point) |
24 V AC/DC |
20 Nm |
S2A |
|
|
Fast Reaction On Off Motor |
SMQ24A |
1 wired control (Open Close) |
24 V AC/DC |
16 Nm |
- |
|
Spring Return Open Close Motor |
NF24A |
Voltage On Off |
24 V AC/DC |
10 Nm |
- |
|
Proportional Motor |
LM24A-SR |
2 - 10 V DC |
24 V AC/DC |
5 Nm |
- |
|
NM24A-SR |
2 - 10 V DC |
24 V AC/DC |
10 Nm |
- |
|
|
SM24A-SR |
2 - 10 V DC |
24 V AC/DC |
20 Nm |
- |
|
|
Spring Return Proportional Motor |
NF24A-SR |
2 - 10 V DC |
24 V AC/DC |
10 Nm |
- |
